ABB Ms116-16 manual motor starter trip class 10a 10 - 16a
Ms116-16 manual motor starter is a compact 45 mm width devices with a rated operational current of Ie = 16.0 a. This device is used to manually switch on and off motors and to protect them reliably an… Les mer …
Kjøp på nett
Sist oppdatert 14. aug., 12:13. Lenkene er annonse-/samarbeidslenker – Prisguider.no kan motta provisjon ved kjøp. Det påvirker ikke prisen din eller rekkefølgen (laveste totalpris vises først).
Produktinfo
Ms116-16 manual motor starter is a compact 45 mm width devices with a rated operational current of Ie = 16.0 a. This device is used to manually switch on and off motors and to protect them reliably and without the need for a fuse from short-circuits, overload and phase failures.
The manual motor starter offers a rated service short-circuit breaking capacity Ics = 16 kA at 400 vac and the trip class 10A. Further features are the build-in disconnect function, temperature compensation, trip-free mechanism and a rotary handle with a clear switch position indication. The manual motor starter is suitable for three- and single-phase applications.
Auxiliary contacts, signalling contacts, undervoltage releases, shunt trips, 3-phase bus bars, power in-feed blocks and locking devices for protection against unauthorized changes are available as accessory.
